TREND DPIL User Manual
Dpil liquid differential pressure sensor, Installation instructions
DPIL Liquid Differential Pressure Sensor Installation Instructions TG200125 Issue 1/E 21/09/05
1
Installation Instructions
DPIL
Liquid Differential Pressure Sensor
Important: Retain these instructions
Dimensions (mm)
1
Requirements
2
Fix bracket
3
100
77
145
a
b
-15 °C
+80 °C
access for
connector screws
not used
do not open
>20
INSTALLATION
