T/av, Averaging temperature sensor, Installation instructions

background image

1

T/AV Averaging Temperature Sensor Installation Instructions 91-2511 Issue 3 27/06/08

Important: Retain these instructions

Installation Instructions

T/AV

Averaging Temperature Sensor

Dimensions

1

INSTALLATION

T/AV Installation
Instructions 91-2511

UNPACKING

Requirements

2

H O

2

-10 °C
+14 °F

+110 °C
+230 °F

0 %RH

95 %RH

measurement ranges

Protection

:IP67, NEMA6

a

-10 °C to +110 °C
+14 °F to +230 °F

-40 °C to +50 °C
-40 °F to +122 °F

b

T/AV-S

Trend Control Systems Horsham

Made in the EU

Foam gasket

Flexible copper tube

IP67 (NEMA 6)
housing

M16 cable gland

85 mm (3.35”)

centres

3.5 m (3.8 yds) (/S) or 7.0 m (7.7 yds) (/L)

97 mm (3.82”)

105 mm (4.13”)

57 mm

(2.24”)

Rigid stainless steel tube

100 mm (3.94”)

/S 6 off
/L 12 off

Ensure no stratification (e.g. downstream of mixing valves,junctions)

c

d

minimum distance from junctions =10xd.
