Bluetooth Adapt Spvr Prt Installation Instructions TG200977 Issue 1/B 25/06/07

3

Installation Instructions

BLUETOOTH ADAPT SPVR PRT

S T A T U S

P O W

E R

For CNC2 or early IQ1xx with a 25 way RS232
connector the additional adaptor
RD/SDU-ADAPTOR IQ1xx can be used

IQ1xx

or

CNC2

25 way

2 terminal

power

signal

RJ11

RJ11

RD/SDU-ADAPTORIQ1xx

24 Vdc
auxiliary

cable supplied

3 Installation

(continued)

Configure Handheld or PC Bluetooth Driver

5

Check Power LED

4

Faulty cable or controller
local supervisor port does
not supply power

OK

S T A T U S

P O W

E R

For Handheld see section 4, For PC see section 5

Check Status LED

6

Not communicating

Communicating with
PC/Handheld

Controller

For IQ22x/ADL remove the modem and plug
in the additional adaptor:
ADAPTOR BLUETOOTH/IQ22xADL.

RJ11

RJ11

cable supplied

IQ22x/ADL

24 Vdc
auxiliary

modem

ADAPTOR BLUETOOTH/IQ22xADL

2 terminal

Connect Bluetooth Supervisor Port Adaptor (BSPA) to Controller

3

(continued)

For later IQ1xx, early IQ21x, early IQ22x, and
IQ250/251 the additional adaptor
RD/SDU-ADAPTOR IQ2xx can be used

For early IQ1xx with a 5 in line RS232 connector
the additional adaptor RD/SDU-ADAPTORIQ1xx+
can be used

RJ11

IQ2xx

RD/SDU-ADAPTOR IQ2xx

RJ11

RJ11

2 terminal

power

signal

24 Vdc
auxiliary

cable supplied

IQ1xx

5 in line

2 terminal

power

signal

RJ11

RJ11

RD/SDU-ADAPTORIQ1xx+

24 Vdc
auxiliary

cable supplied

(dim)

SET 6.02 (or later)
or 916
