SETUP AND INSTALLATION
The following test equipment is required to perform SATA tests.
Equipment Available from LeCroy

Real Time Digital Oscilloscope as listed in Compatibility section with firmware release 6.3.0.0 or later

SDA II is required.

Eye Doctor II is required for channel emulation (6.0Gb/s only) and cable de-embedding.

LeCroy TF-SATA-C Serial ATA Test Fixture includes:

TF-SATA-C Test Fixture

Four 2 inch SSMP(f) to SMA(f) cables

Two SMA 6 dB Attenuators

Multiwrench Tool

LeCroy TF-SATA-C-KIT Serial ATA Measurement Fixture includes:

TF-SATA-C Test Fixture

TF-SATA-C Measurement Fixture

Eight 2 inch SSMP(f) to SMA(f) cables

Two SMA 6 dB Attenuators

Two SMA 50 Ohm Terminators

Two 18 inch SMA to SMA cables

Multiwrench Tool
 50Ω Coax Cable with SMA Male Connectors, qty = 2 (supplied with TF-SATA-C-KIT)

SMA 6dB attenuators, qty = 2 (supplied with TF-SATA-C or TF-SATA-C-KIT)

BIST initiator
Additional Equipment

1 Channel Arbitrary Waveform Generator (for OOB tests)
 50Ω Coax Cable with SMA Male Connectors, qty = 3 (in addition to the 2 listed above, for OOB tests)

1 ISI Channel (for RSG tests)

100ps rise time filter (for RSG tests)

150ps rise time filter (for RSG tests)
Recommended Equipment for BIST initiator

LeCroy PeRT
3
to place the product under tests into the required test mode.

LeCroy Sierra M6-2 or M6-4 6G Protocol Test System to place the product under test (PUT) into the
required test mode.
OR

LeCroy SAS Tracer/Trainer 3G 1 Port Analyzer/Exercise System (SS001APA-X) to place the product
under test (PUT) into the required test mode (1.5Gb/s and 3.0 Gb/s only) includes:
o CATC platform
