TSG-06 – Amplitude Imbalance

TSG-11 –TJ at Connector, 500UI (Edge-Ref) (3.0Gb/s)

TSG-12 –DJ at Connector, 500UI (Edge-Ref) (3.0Gb/s)

OOB-01 – Signal Detection Threshold

OOB-02 – UI During OOB (Bitrate)

OOB-03 – COMINIT and COMWAKE Burst Length

OOB-04 – COMINIT Gap Length

OOB-05 – COMWAKE Gap Length

OOB-06 – COMWAKE Gap Detection

OOB-07 – COMINIT Gap Detection
Note: The waveforms for the demonstration are available from LeCroy as a compacted file SATA Demo Waveforms.zip.
Demo of 6.0 Gb/s Device without SSC
This configuration uses waveforms stored on the oscilloscope in D:\Waveforms\SATA\Demo to demonstrate a
Gen3 device without SSC. The word "Demo" must be entered as Device Under Test in order to run this demo.
The limit set in use is Gen3. All of the variables are set to their default settings except External Attenuation is set
to 0, TestMode is set to Use Saved Data and Filenames point to 6.0Gb/s data files. The tests that are
demonstrated are:

PHY-01 – Unit Interval

PHY-02 – Frequency Long Term Accuracy

TSG-02 – Rise/Fall Times

TSG-03 – Differential Skew

TSG-13 – Gen3 Transmit Jitter

TSG-14 – Gen3 TX Maximum Differential Voltage

TSG-15 – Gen3 TX Minimum Differential Voltage

TSG-16 – Gen3 TX AC Common Mode Voltage

OOB-01 – OOB Signal Detection Threshold

OOB-02 – UI During OOB

OOB-03 – COMINIT and COMWAKE Burst Length

OOB-04 – COMINIT transmit Gap Length

OOB-05 – COMWAKE Transmit Gap Length

OOB-06 – COMWAKE Gap Detection Windows

OOB-07 – COMINIT Gap Detection Windows
Note: The waveforms for the demonstration are available from LeCroy as a compacted file SATA Demo Waveforms.zip.
Empty Template
This configuration is intentionally left blank so it can be used as a base for a user’s custom configuration. The limit
set in use is Gen1i. All of the variables are set to their default settings.
