INTRODUCTION

QPHY-MIPI-DPHY is a software package designed to capture, analyze, and report measurements in conformance
with MIPI Alliance Specification for D-PHY version 1.00.00.

Compatibility

QPHY-MIPI-DPHY is a software option compatible with the following LeCroy X-Stream oscilloscopes:

WavePro 735Zi (4x20GS/s, 2x40GS/s) and higher bandwidth equivalents

SDA 7Zi and DDA 7Zi models are also supported

WaveMaster 804Zi (4x40 GS/s, 2x80GS/s) and higher bandwidth equivalents.

SDA 8Zi and DDA 8Zi models are also supported

SETUP AND INSTALLATION

The following test equipment is required to perform MIPI D-PHY tests.

Required Equipment

Real Time Digital Oscilloscope as listed in Compatibility section with firmware release 6.3.x.x or later,

and software option package QPHY-MIPI-DPHY

QualiPHY Software (version 6.3.0.x or later) installed on either the oscilloscope or a separate PC.

4 x Differential Probes and Platform Cable Assemblies. They can include

o D310 - WaveLink 3.5 GHz 2.5 Vp-p Differential Amplifier Small Tip Module

o D320 - WaveLink 3.5 GHz 5 Vp-p Differential Amplifier Small Tip Module

o D610 - WaveLink 6 GHz 2.5 Vp-p Differential Amplifier Small Tip Module

o D620 - WaveLink 6 GHz, 5 Vp-p Differential Amplifier Small Tip Module

o WL-Plink - WaveLink ProLink Platform/Cable Assembly (4

– 6 GHz)

 WavePro (4 GHz bandwidth or greater) or WaveMaster only

o WL-PBus - WaveLink ProBus Platform/Cable Assembly (3.5 GHz)

o Note: For a complete probe, order a WL-PLink or WL-PBus Platform/Cable Assembly with the

Probe Tip Module.

Optional Equipment (Available from UNH-IOL

– See Images Below)

MIPI D-PHY Reference Termination Board

MIPI TLIS Board

MIPI D-PHY Probing Board

SMA Alignment Fixture

SMA Couplers
