CLKp HS Filename
This variable allows the user to specify the name of the CLKp saved waveform to test. This is only used when
Use Saved Waveforms is set to Yes and Trace Name Format is set to "Custom".
CLKn HS Filename
This variable allows the user to specify the name of the CLKn saved waveform to test. This is only used when
Use Saved Waveforms is set to Yes and Trace Name Format is set to "Custom".
Folder for LP waveforms
This variable allows the user to specify the subfolder inside the folder specified in the Waveform Path variable in
which the LP waveforms will be saved. The default value is ULPS Signals.
ZID termination values for LP (in Ohms)
This allows the user to set the termination values for the lane under test in LP mode. Running test with each value
(50,Open) is a specification requirement. The user can set a subset in case the lane termination cannot be
controlled (partial validation).
Dp Filename
This variable allows the user to specify the name of the Dp saved waveform to test. This is only used when Use
Saved Waveforms is set to Yes and Trace Name Format is set to "Custom".
Dn Filename
This variable allows the user to specify the name of the Dn saved waveform to test. This is only used when Use
Saved Waveforms is set to Yes and Trace Name Format is set to "Custom".
CLKp Filename
This variable allows the user to specify the name of the CLKp saved waveform to test. This is only used when
Use Saved Waveforms is set to Yes and Trace Name Format is set to "Custom".
CLKn Filename
This variable allows the user to specify the name of the CLKn saved waveform to test. This is only used when
Use Saved Waveforms is set to Yes and Trace Name Format is set to "Custom".
HS mode Forward / Reverse direction
This variable is used to compute THS-TRAIL min limit:
(
max( n*8*UI, 60 ns + n*4*UI )
Where n = 1 for Forward-direction HS mode and n = 4 for Reverse-direction HS mode
Reverse-direction is a special mode of transmission of HS-Data. MIPIDPHY spec. definition:
