QPHY-MIPI-DPHY Software Option

918841 Rev

A

31

BRIEF LP RISE & FALL TEST DESCRIPTIONS

Name

Purpose

TRLP-Dp

To verify that the 15%-85% Rise Time (TRLP) of the DUT’s Data & Clock Lanes LP transmitter is

within the conformance limits.

TRLP-Dn

TRLP-CLKp

TRLP-CLKn

TFLP-Dp

To verify that the 15%-85% Fall Time (TFLP) of the DUT’s Data & Clock Lanes LP transmitter is

within the conformance limits.

TFLP-Dn

TFLP-CLKp

TFLP-CLKn

BRIEF LP TIMING TEST DESCRIPTIONS

Name

Purpose

TLP-PER-Data-500

To verify that the period (TLP-PER-TX) of the DUT’s Data Lane LP transmitter XOR

Clock is within the conformance limits.

TLP-PER-Data-930

TLP-PULSE-Data-500

To verify that the pulse width (TLP-PULSE-TX) of the DUT’s Data Lane LP

transmitter XOR Clock is within the conformance limits.

TLP-PULSE-Data-930

FIRST-TLP-PULSE-Data-500

FIRST-TLP-PULSE-Data-930

LAST-TLP-PULSE-Data-500

LAST-TLP-PULSE-Data-930
