Teledyne LeCroy
Verification Script Engine Reference Manual
Page 24 of 115
5.2.1.3 USB3 Packet-specific Set of Members
Note 1: Valid for USB3 packets only, undefined for other events.
Note 2: The system does not pass all possible fields of USB3 packets as members of Input Context. If a script
needs to use the values of those fields, use the
5.2.1.3.1
TSEQ Training Sequence Ordered Set Members
in.Count:
Value of TSEQ count, the number of sequential TSEQ sequences sent
5.2.1.3.2
TS1/TS2 Training Sequence Ordered Set Members
in.Count:
Value of TS count, the number of sequential TS1 or TS2 sequences sent
in.LnkFunctionality:
Value of the whole Link Functionality (Link Configuration) byte in the training
sequence
in.Reset:
Value of the Reset bit in the Link Configuration byte.
in.SSDisable:
Value of the Spread Spectrum bit in the Link Configuration byte.
in.Loopback:
Value of the Loopback asserted/deasserted bit in the Link Configuration byte.
in.ScrDisable:
Value of the Disable Scrambling bit in the Link Configuration byte.
5.2.1.3.3
LFPS Packet Members
in.Type:
Type of LFP signaling
in.Duration:
Duration of LFP signaling in nanoseconds
5.2.1.3.4
Inter-Packet Symbols Packet Members
in.NumOfSymbols:
Number of symbols in the IPS sequence
