80
C HAPTER 14
CATC Scripting Language for USB USB Decoders
Comments
‘Block’ payload cells use view settings contained in global view setting variable
VS
. This way, one view setting can be applied to a block of cells. Note: all
Add...Cell functions use colors as defined in the global variable
FieldColor .
Example
AddBlockPLCellMonoStr("BM class Notice", str,
"This block describes a BaseBoard Management class-
specific part of Notice.\n\n" +
GetBASE_NTooltip());
AddBlockPLCellMonoCap()
AddBlockPLCellMonoCap(caption, text, tooltip, addparam)
addparam Used to create special cells or to modify cell
attributes. The values are predefined constants,
and zero or more of them may be used at one
time. Possible values are:
_ERROR: creates a cell with a red value field to
indicate an error.
_WARNING: creates a cell with a yellow value
field to indicate a warning.
_MONOFIELD: cell consists of only a name
field.
_MONOCOLOR: creates a cell with the same
color in both fields.
_FIXEDWIDTH: creates a cell with a fixed,
specified width.
Parameter Meaning Default Value Comments
caption Displays in the name field of the cell.
text Displays in the value field of the cell.
tooltip Displays in tooltip.
Parameter Meaning Default Value Comments
