HAPTER

CATC Scripting Language for USB

USB Decoders

AddPayLoadCell()

AddPayLoadCell(caption, text, tooltip, addparam)

Comments

Draws a payload cell. Note: all Add...Cell functions use colors as defined in the
global variable FieldColor.

Example

AddPayLoadCell("Field_1", "Value : " +
Format("0x%04X", NextNBits_(16)), "Field 1\n" + "View
setting for this field is set to show field\n" + "both
in collapsed and expanded states.\n\n" + "We use
AddPayLoadCell() to depict this cell.");

AddPayLoadCellMono()

AddPayLoadCellMono(caption, text, tooltip, addparam)

Parameter

Meaning

Default Value

Comments

caption

Displays in the name field of the cell.

text

Displays in the value field of the cell.

tooltip

Displays in tooltip.

addparam

Used to create special cells or to modify cell
attributes. The values are predefined constants,
and zero or more of them may be used at one
time. Possible values are:
_ERROR: creates a cell with a red value field to
indicate an error.
_WARNING: creates a cell with a yellow value
field to indicate a warning.
_MONOFIELD: cell consists of only a name
field.
_MONOCOLOR: creates a cell with the same
color in both fields.
_FIXEDWIDTH: creates a cell with a fixed,
specified width.
