79
C HAPTER 14
CATC Scripting Language for USB USB Decoders
Comments
Used instead of AddPayLoadCell() for cells in group. ‘Block’ payload cells
use view settings contained in global view setting variable VS. This way, one view
setting can be applied to a block of cells. Note: all Add...Cell functions use
colors as defined in the global variable FieldColor.
Example
AddBlockPLCell("Group Field_1", "Value : " +
Format("0x%04X", NextNBits_(16)), "Block Group Field
1" + "\n\nWe use AddBlockPLCell() to depict this
cell.");
AddBlockPLCellMonoStr()
AddBlockPLCellMonoStr(caption, text, tooltip, addparam)
addparam Used to create special cells or to modify cell
attributes. The values are predefined constants,
and zero or more of them may be used at one
time. Possible values are:
_ERROR: creates a cell with a red value field to
indicate an error.
_WARNING: creates a cell with a yellow value
field to indicate a warning.
_MONOFIELD: cell consists of only a name
field.
_MONOCOLOR: creates a cell with the same
color in both fields.
_FIXEDWIDTH: creates a cell with a fixed,
specified width.
Parameter Meaning Default Value Comments
caption Displays in the name field of the cell.
text Displays in the value field of the cell.
tooltip Displays in tooltip.
Parameter Meaning Default Value Comments
