74
C HAPTER 14
CATC Scripting Language for USB USB Decoders
Comments
Draws a monocolor cell that is similar to the usual payload cell except that both the
upper and lower parts of the cell are the same color. Note: all Add...Cell
functions use colors as defined in the global variable FieldColor.
Example
AddPayLoadCellMono("MonoColorField", text, tooltip +
"\n\nWe use AddPayLoadCellMono() to depict this
cell.\n" + "This monocolor cell is similar to usual
payload cell but both upper and\n" + "lower parts of
Cell are depicted by the same color defined for this
attribute\n" + "in file MAD_colors.inc");
AddPLCellMonoStr()
AddPLCellMonoStr(caption, text, tooltip, addparam)
addparam Used to create special cells or to modify cell
attributes. The values are predefined constants,
and zero or more of them may be used at one
time. Possible values are:
_ERROR: creates a cell with a red value field to
indicate an error.
_WARNING: creates a cell with a yellow value
field to indicate a warning.
_MONOFIELD: cell consists of only a name
field.
_MONOCOLOR: creates a cell with the same
color in both fields.
_FIXEDWIDTH: creates a cell with a fixed,
specified width.
Parameter Meaning Default Value Comments
caption Displays in the name field of the cell.
text Displays in the value field of the cell.
tooltip Displays in tooltip.
Parameter Meaning Default Value Comments
