69
C HAPTER 14
CATC Scripting Language for USB USB Decoders
Comments
Writes passed data to out.FieldList as a special field called ‘CAPTION’.
Example
AddCaptionToDlg("Common USB Header", caption + " " +
text, tooltip);
AddStringToDlg()
AddStringToDlg(caption, text, tooltip, addparam)
Comments
Writes passed data to out.FieldList as a special field called ‘STRING’.
Example
AddStringToDlg(caption , text, tooltip);
AddDataBlockToDlg()
AddDataBlockToDlg(len)
Comments
Makes a special record about DataBlock with length equal to len for dialog view.
addparam Used to create special cells or to modify cell
attributes. The values are predefined constants,
and zero or more of them may be used at one
time. Possible values are:
_ERROR: creates a cell with a red value field to
indicate an error.
Parameter Meaning Default Value Comments
caption
text
tooltip
addparam Used to create special cells or to modify cell
attributes. The values are predefined constants,
and zero or more of them may be used at one
time. Possible values are:
_ERROR: creates a cell with a red value field to
indicate an error.
Parameter Meaning Default Value Comments
len
Parameter Meaning Default Value Comments
