Page 84

HAPTER

CATC Scripting Language for USB

USB Decoders

AddSimpleCellMonoCap()

AddSimpleCellMonoCap(caption, text, tooltip, addparam)

Comments

A ‘simple’ payload cell does not respond to view settings. It is always hidden when
collapsed and always shown when expanded. Note: all Add...Cell functions use
colors as defined in the global variable FieldColor.

Example

AddSimpleCellMonoCap("Private", "Data", "This block
contains private data.\n\n" + "This is an example of
datablock.");

AddBlockPLCell()

AddBlockPLCell(caption, text, tooltip, addparam)

Parameter

Meaning

Default Value

Comments

caption

Displays in the name field of the cell.

text

Displays in the value field of the cell.

tooltip

Displays in tooltip.

addparam

Used to create special cells or to modify cell
attributes. The values are predefined constants,
and zero or more of them may be used at one
time. Possible values are:
_ERROR: creates a cell with a red value field to
indicate an error.
_WARNING: creates a cell with a yellow value
field to indicate a warning.
_MONOFIELD: cell consists of only a name
field.
_MONOCOLOR: creates a cell with the same
color in both fields.
_FIXEDWIDTH: creates a cell with a fixed,
specified width.
