HAPTER

CATC Scripting Language for USB

USB Decoders

set Global_BitField_offset = 0;

# global variable

that contains the offset, in bits, from the beginning
of packet for beginning of current attribute. Roughly
speaking, it is the entry point from which an
attribute decoder starts decoding.

set BitCurrentFieldOffset = 0;

# global variable that

contains the offset, in bits, from the starting point
of decoding for the current field inside of the
decoder.

set BitCurrentFieldLength = 0;

# the length, in bits,

of the currently decoded field.

Common Functions

Functions found in DecoderTools2.inc

These are the most commonly-used functions from DecoderTools2.inc.

RGB()

RGB(r, g, b)

Comments

Used to define a color based on red, green, and blue values.

Example

RGB(255, 255, 255); #white

SaveFieldSettings()

SaveFieldSettings()

Parameter

Meaning

Default Value

Comments

r integer

red value

g integer

green value

b integer

blue value

Parameter

Meaning

Default Value

Comments

N/A
