Performance Verification Test Record
This record can be used to record the results of measurements made during the
performance verification of the ZD Series Probes. Photocopy this page and
record the results on the copy. File the completed record as required by
applicable internal quality procedures. The section in the test record
corresponds to the parameters tested in the performance verification
procedure. The numbers preceding the individual data records correspond to
the steps in the procedure requiring the recording of data.
Results to be recorded in the column labeled Test Result are the actual
specification limit check. The test limits are included in all of these steps. Other
measurements and the results of intermediate calculations that support the limit
check are to be recorded in the column labeled Intermediate Results.
Permission is granted to reproduce these pages for the purpose of recording test
results.
NOTE: Use a new Test Record for each tested probe, probe tip module, and lead
assembly.
NOTE: The function generator used in this Performance Verification Procedure is
used for making relative measurements. The output of the generator is
measured with a DMM or oscilloscope in this procedure. Thus, the generator is
not required to be calibrated.
