Operator’s Manual
Item Tested
Item Serial Number Date Technician
ZS
Equipment Used
Instrument Model Serial Number Calibration Due
Date
Oscilloscope
Digital Multimeter
Function Generator
Test Record
O UTPUT Z ERO V OLTAGE
Step Description Intermediate Data
A-5. Output Zero
(Test limit ≤ ±200 μV)
LF A TTENUATION A CCURACY
Step Description Intermediate Data
B-7 Generator Output Voltage V
B-8 Expected Output Voltage, top range V
B-10 Measured Output Voltage, top range V
B-12 Gain Error
, top range (Test Limit ≤ ± 1.0%)
%
B-17 Generator Output Voltage V
B-19 Expected Output Voltage, mid range V
B-21 Measured Output Voltage, mid range V
B-23 Gain Error
, top range (Test Limit ≤ ± 1.0%)
%
