ZS Series High-Impedance, Active Probes
Replacement Parts
The probe connection accessories and other common parts can be ordered
through the North America Customer Care Centers. Refer to Standard
Accessories table after the Introduction of this manual.
Performance Verification
This procedure can be used to verify the warranted characteristics of the
ZS1000, ZS1500, and ZS2500 High Impedance Active Probe.
The recommended calibration interval for the model ZS1000, ZS1500, and
ZS2500 is one year. The complete performance verification procedure should be
performed as the first step of annual calibration. Test results can be recorded on
a photocopy of the Test Record provided in Appendix A at the end of the
manual.
Performance verification can be completed without removing the probe covers
or exposing the user to hazardous voltages. Adjustment should only be
attempted if a parameter measured in the Performance Verification Procedure is
outside the specification limits.
NOTE: Adjustment should only be performed by qualified personnel
This procedure tests the following specifications:
• Output Zero Voltage
• LF Attenuation Accuracy
Required Test Equipment
The Standard Accessories table after the Introduction of this manual lists the
test equipment and accessories (or their equivalents) that are required for
performance verification of the ZS1000, ZS1500, and ZS2500 probes.
This procedure has been developed to minimize the number of calibrated test
instruments required.
Only the parameters listed in boldface in the Minimum requirements column
must be calibrated to the accuracy indicated.
18 924282-00 Rev A
