ZS Series High-Impedance, Active Probes
3. Turn on the other test equipment and allow them to warm up for the
manufacturer’s recommended timeframe.
4. While the instruments are reaching operating temperature, make a
photocopy of the Performance Verification Test Record (located in
Appendix A), and fill in the necessary data.
5. Select the channel to which the probe is connected. Set the
oscilloscope scale factor to 20 mV/div.
6. Disconnect the ProBus Extender Cable from the oscilloscope. Verify
that the scale factor changes from 20 mV/div to 2 mV/div.
7. Reconnect the ProBus extender Cable to the oscilloscope.
The warranted characteristics of the ZS1000, ZS1500, and ZS2500 are valid at
any temperature within the Environmental Characteristics listed in the
Specifications. However, some of the other test equipment used to verify the
performance may have environmental limitations required to meet the accuracy
needed for the procedure. Be sure that the ambient conditions meet the
requirements of all the test instruments used in his procedure.
NOTE: The correct operation of the ZS2500 controls requires software version
6.5.0.5 or higher. The software version in the test oscilloscope can be verified by
selecting Utilities → Utilities Setup → Status tab.
Contact your local Teledyne LeCroy representative or visit teledynelecroy.com if
the software in your oscilloscope requires updating.
Functional Check
The functional check verifies the basic operation of the probe functions. It is
recommended that the Functional Check be performed prior to the Performance
Verification Procedure.
1. Return to the factory default settings by:
• Selecting File → Recall Setup... from the menu bar.
• Then touch the Recall Default button.
2. Touch the C1 trace label to open the C1 Vertical Adjust dialog.
3. Verify that the probe model is sensed and displayed on the Probe tab.
20 924282-00 Rev A
