42 ISSUED: September 2005 WE-GS-E Rev A
(then Utilities
Setup...)
Scope Icons
The icons that you see in the dialog areas of the scope are touch sensitive. When selected, an
icon changes color to show that it is active. The Trigger setup dialog is an example of this
functionality.
Other icons, for example those located at the bottom of the Vertical Adjust setup dialog, are
quick links to other functions, such as Math and Measure.
Dialog Boxes
The dialog area occupies the bottom one-third of the screen. To expand the signal display area,
you can minimize each dialog box by touching the Close tab at the right of the dialog box.
