34

ISSUED: September 2005

WE-GS-E Rev A

Vertical Knobs and Buttons:

O

FFSET

Adjusts the vertical offset of a

channel.

V

OLTS

/D

IV

Adjusts the Volts/Division setting

(vertical gain) of the channel selected.

C

HANNEL

B

UTTONS

Turn a channel on or off.

These buttons activate the dialog that lets you
change the channel's setup conditions
including coupling, gain, and offset. They are
used also to select multiple grids, to
automatically set the gain (Find Scale), or to
automatically display a zoom of the signal.
Press twice to toggle the trace on and off.

Horizontal Knobs and Buttons:

D

ELAY

Horizontally positions the scope trace

on the display so you can observe the signal
prior to the trigger time.

T

IME

/D

IVISION

Sets the time/division of the

scope timebase (acquisition system).

C

ALIBRATE

Calls up the SMART Memory

dialog from the Horizontal setup menus.

Z

ERO

D

ELAY

Sets the horizontal delay to

zero. The trigger point is positioned at the left
edge of the display grid.

S

ETUP

Activates the TIMEBASE menu to

allow you to select acquisition conditions,
including the sample mode, maximum memory
length, etc.
