User Guide: FAAST Fire Alarm Aspiration Sensing Technology® Modbus Protocol Schema 1
16
Device Configuration (Cont’d)
Address Size
(16-bit
words) Parameter Name Type Description
372-373 2 ∆ Fire2 Night Threshold F32 Fire2 Alarm Night Obscuration Threshold
374-375 2 ∆ Fire2 Weekend Threshold F32 Fire2 Alarm Weekend Obscuration Threshold
376-377 2 ∆ Alert Acclimate Threshold Max F32 Maximum Alert Alarm Threshold when operating in
Acclimate ® Mode
378-379 2 ∆ Alert Acclimate Threshold Min F32 Minimum Alert Alarm Threshold when operating in
Acclimate Mode
380-381 2 ∆ Action1 Acclimate Threshold Max F32 Maximum Action1 Alarm Threshold when operating in
Acclimate Mode
382-383 2 ∆ Action1 Acclimate Threshold Min F32 Minimum Action1 Alarm Threshold when operating in
Acclimate Mode
384-385 2 ∆ Action2 Acclimate Threshold Max F32 Maximum Action2 Alarm Threshold when operating in
Acclimate Mode
386-387 2 ∆ Action2 Acclimate Threshold Min F32 Minimum Action2 Alarm Threshold when operating in
Acclimate Mode
388-389 2 ∆ Fire1 Acclimate Threshold Max F32 Maximum Fire1 Alarm Threshold when operating in
Acclimate Mode
390-391 2 ∆ Fire1 Acclimate Threshold Min F32 Minimum Fire1 Alarm Threshold when operating in
Acclimate Mode
392-393 2 ∆ Fire2 Acclimate Threshold Max F32 Maximum Fire2 Alarm Threshold when operating in
Acclimate Mode
394-395 2 ∆ Fire2 Acclimate Threshold Min F32 Minimum Fire2 Alarm Threshold when operating in
Acclimate Mode
396 ½ ID Number U8 Can be used for the SLC address or an identification
number on a loop
Flashscan 1-Address: 1-159
Flashscan 5-Address: 1-155
CLIP: 1-99
397-428 32 Contact U8[64] UTF-16 Contact Name string buffer
431-460 32 Facility U8[64] UTF-16 Facility Name string buffer
461-492 32 Facility Location U8[64] UTF-16 Facility Location string buffer
493-524 32 Device Location U8[64] UTF-16 Device Location string buffer
525-527 3 Button Lock U8[3] User Interface Lockout
Unlocked 0
Locked 1
Bit 0: Isolate
Bit 1: Reset/Mode
Bit 2: Test
528-529 2 Passcode U32 Passcode for unlocking the buttons from the front panel.
Unsigned Long Value: 1111-9999
Table 7. Device Configuration Modbus Holding Registers
∆ Warning!! Device threshold configuration variables should be set by the user to values scaled based on the Units configuration
setting. The detector will interpret the value differently for different Units settings. E.g. The device will interpret a 0.01 threshold
setting as 0.01 %/ft when Units setting is US Standard. The device will interpret a 0.01 threshold setting as 0.01 %/m when Units
setting is Metric.
