3" SIDEBAR

2014 SORENTO

Page 5 of 6

10/3/13 (DP)

Driver Side Installation Pictured















































Fig 10

Fig 11

Fig 12

(Fig 13B) Insert Spacer between Bracket and frame
channel if additional adjustment is required

Rear

Rear

Front

Front

Fig 13A

Remove plastic
deflector

Use clamp to temporarily hold front Bracket
up to pinch weld until final installation

(2) 8mm x 25mm Hex Bolts
(2) 8mm Lock Washers
(2) 8mm Flat Washers

(2) 8mm x 25mm Hex Bolts
(2) 8mm Lock Washers
(2) 8mm Flat Washers

Mark the Bracket location onto back of
pinch weld. Do not drill until after Sidebar
is properly aligned and adjusted
