Steelcraft Automotive 280310 3 ROUND SIDE BAR User Manual
Page 4
3" SIDEBAR
2014 SORENTO
Page 4 of 6
10/3/13 (DP)
Driver Side Installation Pictured
(Fig 9A) Insert Spacer between
the Bracket and the body panel
Fig 8B
Fig 7
(Fig 8A) 12mm x 40mm
Short Low Profile Bolt Plate
12mm x 40mm Short
Low Profile Bolt Plate
12mm Lock Washer
12mm Flat Washer
12mm Hex Nut
Rear
Rear
Fig 9B
Rear
Remove plug
Insert Spacer between the Bracket and the body panel
Fig 9C
Spacer
