Steelcraft Automotive 114000 RUNNING BOARD User Manual
Page 7
VIEWPOINT RUNNING BOARDS
2013 FORD ESCAPE
Page 7 of 7
9/12/12 (DP)
Driver Side Installation Pictured
Complete Installation
6mm x 22mm Flat Washers
6mm Lock Washer
6mm Hex Nut
Insert T-Bolts into
channel and slide
into position
(Fig 24) Rotate front Bracket back to clear
slots for T-Bolts on bottom of Board
(Fig 22B) Do not cut mounting area off of cover
Front
Front
(Fig 22A) Dashed line represents
area to cut from cover to clear
Bracket
Fig 23
Fig 25
