VIEWPOINT RUNNING BOARDS
2013 FORD ESCAPE
Page 4 of 7 9/12/12 (DP)
Driver Side Installation Pictured
Fig 6
(2) 10mm Flat Washers
(2) 10mm Lock Washers
(2) 10mm Hex Nuts
40"
(Fig 11) Hold center Bracket up in
place to determine area to cut from
bottom edge of rocker panel cover
Front Rear
(Fig 8) Measure approximately 40inches from
bottom corner of wheel opening along rocker
panel to locate factory hole for center bracket
(Fig 7) Release all clips along
bottom of rocker panel cover
(Fig 9) 10mm x 30mm Bolt Plate
(Fig 10) 10mm x 30mm Bolt
Plate with Plastic Retainer
