2

Dimensions

Figure 1. 175721.00 (Chassis) Dimensions

8.90 [226]

8.38 [213]

3.53 [90]

4.75 [120]

1.86 [47]

0.92 [23]

ALL DIMENSIONS IN INCHES [MILLIMETERS]
