16

Factory Prewired Connections

(for Cased Drives)

1

2

3

WHITE/BLACK

WHITE/BLACK

WHITE/BLACK

L2 (230)

L2 (115)

L1

BLACK/WHITE

BLACK

BLACK

POWER

LIGHT

BLACK

Figure 10. Prewired Connections to L1, L2 (with 115 VAC input)

and L2 (with 230 VAC input)
