6

Installation should be performed by competent technicians in accordance with local and state codes. In the

absence of these codes, installation must conform to applicable AMERICAN NATIONAL STANDARDS:

National Fuel Gas Code ANSI Z223.1-LATEST EDITION

and/or

National Electric Code ANSI/NFPA No. 70-LATEST EDITION

A. Enclosure, Air Supply, and Exhaust Requirements

NOTE: The following information is very brief and general. For detailed description, refer

to the Installation Manual supplied with dryer.

Bulkheads and partitions around the dryer should be made of noncombustible materials. Allowances should be

made for the opening and closing of the control door and lint door. Also, allowances should be made in the rear

for ease of maintenance. (Refer to appropriate Installation Manual for recommended distances and minimum

allowances required.)

When the dryer is operating, it draws in room air, heats it, passes this air through the basket (tumbler), and

exhausts it out of the building. Therefore, the room air must be continually replenished from the outdoors. If the

make-up air is inadequate, drying time and drying efficiency will be adversely affected. Ignition problems and

sail switch "fluttering" problems on gas dryers may result, and you also could have premature motor failure

from overheating. The air supply must be given careful consideration to insure proper performance of each

dryer.

IMPORTANT: Make-up air must be provided from a source free of dry cleaning fumes.

Make-up air that is contaminated by dry cleaning fumes will result in

irreparable damage to motors and other dryer components.

Exhaust duct work should be designed and installed by a competent technician. Improperly sized duct work

will create excessive back pressure which will result in slow drying, increased use of energy, and shutdown of

the burner by the airflow (sail) switch, burner hi-limit or lint chamber hi-heat protector thermostat. (Refer to

appropriate Installation Manual for more detail.)

CAUTION: IMPROPERLY SIZED OR INSTALLED EXHAUST DUCT WORK CAN

CREATE A POTENTIAL FIRE HAZARD.

SECTION III

Installation Requirements
