Harrington Hoists and Cranes ED-DA Hoist - (ED3) - Manual (Page 9)

9
Table 2-1 Hoist Motor Rating
Cap.
(lbs.)
Product Code Motor
Intermittent Duty
Rating
Short
Time
Duty
Rating
(min)
Rated
Current
at 120V
(amps)
Single
Speed
S Model
Dual
Speed
DS Model
Dual
Adjustable
DA Model
Output
(Hp)
Rated
Current
at 115V
(Amps)
Duty
Rating
% ED
Max. Start
Freq.
(Times/Hr)
125 ED125S ED125DS ED125DA
0.4
5 30 180 15 5
220 ED220S ED220DS ED220DA
250 ED250S ED250DS ED250DA 6 20 120 10 6
350 ED350S ED350DS ED350DA 0.8 10 30 180 20 10
400 ED400S ED400DS ED400DA 0.4 6 20 120 10 6
525 ED525S ED525DS ED525DA 0.8 10 30 180 20 10
Table 2-2 Hoist Specifications
Cap.
(lbs.)
Product Code
Lifting Speed
(ft/min)
Load
Chain
Wire
Diameter
(mm) x
Chain Fall
Lines
Load
Sheave
Pockets
Net Weight
(lbs.)
Weight for
Additional One
Foot of Lift
(lbs.)
Single
Speed
S Model
Dual
Speed
DS Model
Dual
Adjustable
DA Model
S
Model
DS &
DA
Model
S
Model
DS
Model
DA
Model
S
Model
DS
Model
125 ED125S ED125DS ED125DA 69 69/13
4.0 x 1
4
23 24 31
0.26 0.29
220 ED220S ED220DS ED220DA 43 43/10
250 ED250S ED250DS ED250DA 26 26/10 24 25 32
350 ED350S ED350DS ED350DA 66 66/13 5 33 34 40
400 ED400S ED400DS ED400DA 26 26/10 4 24 25 32
525 ED525S ED525DS ED525DA 44 44/10 5 33 34 40
