Page 10
10
2.2
Dimensions
Table 2-3
Hoist Dimensions
Cap.
(lbs)
Headroom
C
(in)
Standard Lift
L
(ft)
Push Button Cord
L
(ft)
a
(in)
d
(in)
e
(in)
f
(in)
g
(in)
h
(in)
i
(in)
j
(in)
k
(in)
S & DS
Model
DA
Model
S & DS
Model
DA
Model
S & DS
Model
S & DS
Model
EDII EDIII EDII
EDIII
125
11.8
12.4
36.6
37.2
10
6
8
Coiled
14.6
7.4
7.2
8.1
1.0
4.9
3.1
1.0
13.4
220
250
350
12.8
13.0
37.6
37.8
16.9
8.1
8.8
8.6
5.3
3.3
14.3
400
11.8
12.4
36.6
37.2
14.6
7.4
7.2
8.1
4.9
3.1
13.4
525
12.8
13.0
37.6
37.8
16.9
8.1
8.8
8.6
5.3
3.3
14.3
Figure 2-1
Hoist Dimension for S and DS Models
(See Table 2-3)
Figure 2-2
Hoist Dimension DA Models
(See Table 2-3)
