39
9.0 Parts List
When ordering Parts, please provide the Hoist code number, lot number and serial number located on the Hoist
nameplate (see fig. below).
Reminder: Per sections 1.1 and 3.9.4 to aid in ordering Parts and Product Support, record the Hoist code
number, lot number and serial number in the space provided on the cover of this manual.
ED Nameplate
The parts list is arranged into the following sections:
Section Page
9.1 Housing, Motor, and Gearing Parts……………………………………………………………………...40
9.2 Power Supply and Pendant Parts ………………………………………………………………………44
9.3 Electric Parts ……………………………………………………………………………………………...48
9.4 Mini Trolley Parts………………………………………………………...………………………………..50
A designator is used to distinguish parts that apply only to a particular model or option. Refer to Section 2 for
hoist model numbers and additional descriptions. The designators are:
S = Single Speed
DS = Dual Speed
DA= Dual Adjustable Speed
