11
Figure 2-3 ET525 Mini Trolley (See Tables 2-4 and 2-5)
Table 2-4 Mini Trolley Dimensions
Maximum
Capacity
(lbs.)
Product
Code
Adjustable
Beam Width
B
(in)
Min. Radius
for Curve
(in)
Net
Weight
(lbs.)
Approx.
Shpg.
Weight
(lbs.)
525 ET525 1.97 – 3.94 23.6 4.0 5.0
Table 2-5 Mini Trolley Headroom
Cap.
(lbs.)
Headroom C (in.)
ED II ED III
S & DS
Model
DA Model
S & DS
Model
DA Model
125
9.9 34.5 10.5 35.3 220
250
350
10.9 35.7 11.1 35.9
400 9.9 34.5 10.5 35.3
525 10.9 35.7 11.1 35.9
Table 2-6 ED Hook Dimensions*
Capacity
(lbs.)
Hook
a
(in)
b
(in)
c
(in)
d
(in)
e
(in)
f
(in)
g
(in)
125 to 525
Top 0.8 0.3 0.7 0.3 1.3 1.2 1.0
Bottom 0.8 0.5 0.7 0.5 1.4 1.4 1.0
*See Table 5-5 for discard dimensions.
Table 2-7 ED Chain Dimensions
Cap.
(lbs)
Product
Code
d
(in)
a
(in)
b
(in)
P
(in)
125
to
525
(All Models) 0.16 0.20 0.53 0.48
