9.3 Electric Parts
Fig.
No.
Part Name
Parts
Per
Hoist
Capacity (lbs.)
125
220
250
400
350
525
1
Control Panel Complete Set
1
E2D1601P125
E2D1601P350
2
Converter Assembly
1
E2D616125
E2D616350
3
Fuse
1
E2D664125
E2D664350
4
Silicone Stack Assembly
1
E2D622125
E2D622350
5
Machine Screw w/ Spring Washer
(for converter)
2
E2D667125
6
Machine Screw w/ Spring Washer
(for silicone stack)
1
MS557010
7
Electromagnetic Contactor
2
E2D617P125
Electromagnetic Contactor Complete Set
1
E2D617P350
8
Machine Screw w/ Spring Washer
(for Contactor)
4
MS555010
Machine Screw w/ Spring Washer (for base)
4
E2D667125
9
Resistor
1
E2D619P125
E2D619P350
10
Machine Screw w/ Spring Washer
(for resistor)
9
MS557010
11
Socket Bolt w/ Spring Washer
3
E2D651125
4
E2D651350
21
Control Panel Complete Set
1
E2D1601PD125
E2D1601PD350
22
Converter Assembly
1
E2D616PD125
E2D616PD350
23A Fuse F2
1
E2D664125
E2D664350
23B Fuse F3 (0.1 AMP)
1
9006237
24
Silicone Stack Assy.
1
E2D622125
E2D622350
25
Machine Screw w/ Spring Washer
(for converter)
2
E2D667125
26
Machine Screw w/ Spring Washer
(for silicone stack)
1
MS557010
27
Electromagnetic Contactor
2
E2D617P125
Electromagnetic Contactor Complete Set
1
E2D617P350
28
Machine Screw w/ Spring Washer
(for Contactor)
5
MS555010
Machine Screw w/ Spring Washer (for base)
2
E2D667125
29
Resistor
1
E2D619P125
E2D619P350
30
Machine Screw w/ Spring Washer
(for resistor)
9
MS557010
31
Socket bolt w/ Spring Washer
3
E2D651125
4
E2D651350
