27
5.5 Occasionally Used Hoists
5.5.1 Hoists that are used infrequently shall be inspected as follows prior to placing in service:
 Hoist Idle More Than 1 Month, Less Than 1 Year: Inspect per FREQUENT Inspection criteria in
Section 5.3.
 Hoist Idle More Than 1 Year: Inspect per PERIODIC Inspection criteria in Section 5.4.
5.6 Inspection Records
5.6.1 Dated inspection reports and records should be maintained at time intervals corresponding to those
that apply for the hoist’s PERIODIC interval per Section 5.2.4. These records should be stored where
they are available to personnel involved with the inspection, maintenance, or operation of the hoist.
5.6.2 A long range chain inspection program should be established and should include records of
examination of chains removed from service so a relationship can be established between visual
observation and actual condition of the chain.
5.7 Inspection Methods and Criteria
5.7.1 This section covers the inspection of specific items. The list of items in this section is based on those
listed in ANSI/ASME B30.16 for the Frequent and Periodic Inspection. In accordance with ANSI/ASME
B30.16, these inspections are not intended to involve disassembly of the hoist. Rather, disassembly for
further inspection would be required if frequent or periodic inspection results so indicate. Such
disassembly and further inspection should only be performed by a qualified person trained in the
disassembly and re-assembly of the hoist.
Table 5-3 Hoist Inspection Methods and Criteria
Item Method Criteria Action
Functional operating
mechanisms.
Visual, Auditory
Mechanisms should be properly adjusted and
should not produce unusual sounds when
operated.
Repair or replace
as required.
Limit Switch
(model ED3)
Function
Proper operation. Actuation of limit switch should
stop hoist. Repair or replace
as required.
Braking System
Operation
Function
Braking distance with rated capacity should not
exceed approximately five chain links. Repair or replace
as required.
Hooks - Surface
Condition
Visual
Should be free of significant rust, weld splatter,
deep nicks, or gouges.
Replace.
Hooks - Fretting
wear
Measure
The "u" and "t" dimensions should not be less
than discard value listed in Table 5-5
Replace.
Hooks - Stretch Measure
The "k" dimension should not exceed the
measured value for discard from Table 5-5 (See
Section 3.9).
Replace.
Hooks - Bent Shank
or Neck
Visual
Shank and neck portions of hook should be free
of deformations.
Replace.
Hooks - Yoke
Assembly
Visual
Should be free of significant rust, weld splatter,
nicks, gouges. Holes should not be elongated,
fasteners should not be loose, and there should
be no gap between mating parts.
Tighten or replace
as required.
