6-4 Communication Setting
The procedure for setting the communication protocol to communicate with a computer is shown below.
Power Up
1.MEASURE MODE 2.DATA PROCESSING 3.OPTIONS
< OPTION >
1. ALARM 4. HOTKEY 2. UNITS 5. AUTOST. 3. UTILITIES
Press ENTER key
< UTILITIES >
1.DATE 2005/08/05 2.TIME 13:29 3.ID 00(MAX 31)
Change the values by using the ▲▼ key. Move the cursor to the “ID” row by pressing the ENTER key.
2005/08/05 ↓ 2005/08/05 ↓ 2005/08/05 ↓ 2005/08/05 ↓ 2005/08/05 ↓ 2005/08/05 ↓ 13:29 ↓ 13:29 ↓ 13:29 ↓ 13:29 ↓ 00 ↓ 00 ↓ RS232C
When using the supplied software, “ID” must be set to “00”, and “COMMUNICATION” must be set to “RS232C”.
Change setting by using the ▲▼ key.
RS232C←→RS485
4. COMMUNICATION
RS232C
Press PREV key
Change ID number by using the ▲▼ key.
