RMA-303 Indirect Charge - Installation
33 LN-9268-11.4
Ransburg Filter
Model No. Description / Specifications Replacement Ele-
ment Part No.
HAF-503 Pre-filter, removes coarse amounts of oil, moisture
and dirt. Used upstream of HAF-508 pre-filter
(used in systems with poor air quality. HAF-15 Element One
HAF-508 Pre-filter, coalescing type, 136 SCFM, 98.5% effi-
ciency particulate removal .3 to .6 micron, max.
aerosol passed 1.0 micron, max. solid passed .4
micron (dependent upon SCFM requirement per
applicator, one HAF-508 can be used with up to
three RMA-303 assemblies). HAF-38 Elements,
Carton of 4
RPM-418 Bearing air filter, coalescing type,19 SCFM,
99.995% efficiency particulate removal .3 to .6 mi-
cron, max. RMA-303 passed .6 micron max. solid
passed .2 micron (one per RMA-303
)
RPM-33 Elements,
Carton of 8
AIR FILTRATION REQUIREMENTS
N O T E Volume Booster Recommendation (Turbine
Air):
Ransburg Part # A11111-00
•
Pilot Operated Regulator Non-Bleed Pilot
•
SCFM-200
•
Supply - 300 P.S.I.
•
Temperature Range: 40˚ - 120° F
> Each applicator must have its own
filter for bearing air. Recommended:
RPM-418 or equivalent
