Parts identification (cont.) – Ransburg MMA-303 Direct_Ind Charge Atomizer A12870 User Manual
Page 115
MMA-303 Direct/Indirect Charge - Parts Identification
LN-9269-11.3
112
PARTS IDENTIFICATION (Cont.)
SHAPING AIR KIT - PARTS LIST
Item #
Part #
Description
Qty
1
A
Outer Shroud
1
2
B
Shaping Air Ring
1
3
C
Inner Shaping Air Ring
N
4
D
Turbine Retaining Ring
1
5
79001-11
O-Ring, Solvent Proof
1
6
79001-52
O-Ring, Solvent Proof
P
7
E
Repulsion Ring
R
8
77580-08C
Screw, 6-32X1/4" LG Button Cap Screw, SS
S
NOTE
- Set screw for all shaping air configurations is A12253-00.
TUBING BUNDLE NOMENCLATURE
SAO
Shaping Air, #2
SAI
Shaping Air, #1
BA
Bearing Air Supply
BRG, RTN
Bearing Air Return
PD
Dump Trigger
DL
Dump Out
PT
Paint Trigger
P
Paint Supply
ST
Solvent Trigger
SOL
Solvent Supply
TA
Turbine Air Supply
LV
Low Voltage Cable Port
FO
Fiber Optic Cable Port
CWA
Cup Wash Air
ATI
Cup Wash Air Trigger
BRK
Brake Air
