Aerobell Control Module Assembly 78387-00
1 Regulator, Pilot, 0-60 psi 76648-02 REG1, REG2, REG3
2 Air Piloted Air Valve, NO 41-VAP-1000 PV3
3 Shuttle Valve 41-VSH-1000 SV1
4 Solenoid, 12 VDC 78393-01 SOL1
5 Air Piloted Air Valve, Low Acting, NC 41-VMP-1003 PV1, PV2
6 Sensing Valve SSV-3206 SNS1
7 Switch, Air Toggle, NC, Momentary 76647-02 SW4, SW5
8 Switch, Air Toggle, NC 76647-01 SW1, SW2, SW3, SW6
9 Pressure Gauge, 0-60 psi 76646-06 G1, G2, G3
Remote Manifold 78395-00
10 Filter, Bearing Air RPM-418
Filter Element Only (Set of 8) RPM-33
11 Volume Booster, Pilot Operated 76736-00
12 Pressure Gauge, 0-160 psi GA-316
13 Filter/Regulator Assembly 76775-01
Filter Element Only 76192-02
Item #
9040 AEROBELL CONTROL MODULE - PARTS LIST (Figure 10)
Part # Description Notation
10 Filter Element, Bearing Air Filter (Set of 8) RPM-33
13 Filter Element, Remote Manifold Filter 76192-02
RECOMMENDED SPARE PARTS
Part # Item # Description
9040 Aerobell Control Module - Parts Identification
