INSTALLATION
LOCATION
Control Module
Install the 78387-00, Aerobell Control Module (see
Figure 1), in an area OUTSIDE the hazardous
location, but as close to the applicator as possible,
to minimize the length of tubing runs. The area
should provide protection from the possibility of
environmental intrusion, such as dust or moisture,
and ambient temperatures in excess of 120 o F.
Remote Manifold
The 78395-00 Remote Manifold (see Figure 1)
may be mounted in a convenient area inside or
outside the hazardous location. Minimization of
tubing runs should be considered when mount-
ing the remote manifold. Mount the bearing air
filter as close to the applicator as possible.
MOUNTING
Each 9040 Single Bell Package is supplied with a
mounting kit. These kits are different for Standard
RPM Aerobells and Aerobell 33’s. Before proceed-
ing further with installation of the Aerobell Module,
ensure these kits are installed as described below.
Standard (RPM) Aerobell
Connect the fluid regulator and trigger/dump valve
assembly to the RPM Aerobell using the supplied
fittings, as shown in Figure 2. Connect the Aerobell
to the RPM mounting arm as shown. The mount-
ing arm may be connected to an optional stand
(P/N LA0041) or to a reciprocator using an optional
LRPM0106 bracket.
Aerobell 33
Connect the Aerobell 33 to the mounting arm as
shown in Figure 3. The mounting arm may be
connected to an optional stand (P/N LA0041) or
to a reciprocator using an optional LRPM0106
bracket. Mount the solvent flush manifold in an
easy to reach location near the applicator. Ensure
the solvent flush manifold is grounded to true
earth ground.
>
This manual MUST be read and thor-
oughly understood by ALL personnel who
operate, clean, or maintain this equipment!
Special care should be taken to ensure that
the WARNINGS and safety requirements
for operating and servicing the equipment
are followed. The user should be aware of
and adhere to ALL local building and fire
codes and ordinances, as well as NFPA-
33, prior to installing, operating, and/or
servicing this equipment.
W A R N I N G
!
>
To prevent material backup into the
Aerobell 33 the flow of solvent from the
applicator should never exceed 500 cc’s/
minute. The flow can be adjusted below
this value using the adjustment knob on
the solvent flush manifold. The solvent
supply should be connected to the fluid
input of the solvent flush manifold. The
fluid output of the solvent flush manifold
should be connected to the solvent fluid
input of the applicator.
NOTE
>
Do not locate the control module near
or adjacent to heat producing equipment
such as ovens, high wattage lamps, etc.
NOTE
