Remote Manifold
Shaping Air Regulator Output
Air output from remote manifold used to shape
the spray pattern of the applicator. Using 3/8-inch
OD tubing, connect “SHAPING AIR REGU-LATOR
OUTPUT” of the remote manifold to the shaping
air input of the applicator.
Atomization Air Regulator Output
Air output from remote manifold used to control
the turbine speed of the applicator. Using 1/2-inch
OD tubing, connect “ATOMIZATION AIR REGU-
LA-TOR OUTPUT” of the remote manifold to the
atomization/turbine air input of the applicator.
Remote Manifold Main Air Out / Bearing
Air Filter Input
Main air output of remote manifold used to supply
main air to bearing air filter. Using 3/8-inch OD
tubing, connect “REMOTE MANIFOLD MAIN
AIR OUT” to “BEARING AIR FILTER INPUT” of
bearing air filter.
Bearing Air Filter
Bearing Air Filter Output
Air output used to supply filtered bearing air to
the applicator. Using 1/4-inch OD tubing, connect
“BEARING AIR FILTER OUTPUT” to bearing air
input of applicator.
FLUID CONNECTIONS
Using 3/8-inch OD adhesive tube, make the ap-
propriate fluid connections as described in the
Applicator Service Manual.
NOTE
>
Adhesive tape, pipe dope, or other
thread sealant material should not be
used downstream of the bearing air filter.
