"FLD"
0 to 60 psi pilot regulator output that is used as
a pilot signal to operate the fluid regulator at the
applicator. Using 1/4-inch OD tubing, connect
“FLD” output to pilot air input of applicator fluid
regulator.
"ATM"
0 to 60 psi pilot regulator output used as input to
atomization air volume booster on remote man-
ifold. Using 1/4-inch OD tubing, connect “ATM”
output to ATOMIZATION AIR PILOT INPUT of
remote manifold.
"ATMR"
Input from remote manifold used to display the
pressure of the atomization air remote manifold
volume booster on the ATM gage of the control
module. Using 1/4-inch OD tubing, connect
“ATMR” input to ATOMIZATION AIR GAGE OUT-
PUT of remote manifold.
"SHP"
0 to 60 psi pilot regulator output used as input to
shaping air volume booster on remote manifold.
Using 1/4-inch OD tubing, connect “SHP” output to
SHAPING AIR PILOT INPUT of remote manifold.
"SHPR"
Input from remote manifold used to display the
pressure of the shaping air remote manifold
volume booster on the SHP gage of the control
module. Using 1/4-inch OD tubing, connect
“SHPR” input to SHAPING AIR GAGE OUTPUT
of remote manifold.
"BA"
Input from Aerobell used to ensure at least 60
psi turbine air pressure before allowing fluid to
the bell. Using 1/4-inch OD tubing, connect “BA”
input to bearing air output of Aerobell (see currrent
Aerobell service manual).
"DMP"
Air output used to activate applicator dump valve.
Using 1/4-inch OD tubing, connect “DMP” to air
trigger input of dump valve at the applicator.
"SOLV"
(For Aerobell 33 versions only; not used for
standard RPM Aerobells.)
Air output used to activate applicator solvent valve.
Using 1/4-inch OD tubing and 1/4-inch tee fitting,
connect “SOLV” to air trigger input of solvent valve
at the applicator and to the air trigger input of the
LRPM6009-01 Solvent Flush Manifold.
"TRG"
Air output used to activate applicator trigger valve.
Using 1/4-inch OD tubing, connect “TRG” to air
trigger input of trigger valve at the applicator.
>
The high voltage connection MUST be
made to ensure that high voltage is OFF
during solvent or dump operations.
!
>
For standard RPM Aerobells there is
no bearing air output signal from the bell
itself. In this case insert a 1/4-inch OD
tee fitting in the bearing air input line to
the bell and connect the outlet of the tee
to “BA”. Make this connection as close to
the bell as possible.
NOTE
9040 Aerobell Control Module - Installation
