Command T
ype (hex)
Response Or
Action From User Interface
Response Or
Action From Interface Module
<13>
Request to Stop Calibration for a Channel: <13><0C> Where: 1) = message length = <01h>. 2) <0C> = Channel #.
Response: <13><0C> Where: 1) = message length = <07h>. 2) <0C> = Channel #. 3) = Calibration Control word. 4) = # pulses received during calibration. 5) = calibration time.
<14>
Request to Copy
Attached Pulses Per Liter to a Range of
Jobs: <14> Where: 1) = message length = <07h>, 2) = pulses per liter
.
3) = starting target Job #. 4) = starting target Channel #. 5) = ending target Job #.
Response: ACK Note: W
ait 200 milliseconds before issuing another command to
allow the Interface Module time to complete the transfer
.
<15>
Send Current Status of Gun Keys: <15><0G> Where: 1) = message length = <03h>. 2) <0G> = Gun #. 3) = Operator Status word (see below). Operator Status word: Bit 0 =
Trigger
Bit 1 =
Active mode
Bit 2 = Halt Bit 3 = Clean mode Bit 4 = Bit 5 = Calibration mode Bit 6 = Reset Gun Fault Bit 7 = Bit 8 = Bit 9 = Bit 10 = Load Mode Bit 1
1 =
Bit 12 =
Auto-tune mode
Response: ACK
39
