Command T
ype
(hex)
Response Or
Action From User Interface
Response Or
Action From Interface Module
Where: 1) = message length = <01h>. 2) <0G> = Gun #.
Where: 1) = message length = <10h> 2) <0G> = Gun # 3) = Filtered Master Channel Flow Rate 4) = Filtered Slave Channel Flow Rate 5) = Gun Status word (see below). 6) = Current trigger status, <00> = OFF
, and = ON
7)
=
Filtered
Curent
ratio
x
100.
8) =
Analog set point in CC/min.
9) = Filtered Master Channel voltage output. 10) = Filtered Slave Channel voltage output. 1
1) = Job Queue.
12) =
Active Job #.
Gun Status word: Bit
0
=
Pot
Life
T
imer
Expired
Bit 1 =
Active
Bit 2 = Halted Bit 3 = Clean Mode Bit 4 = Enabled Bit 5 = Calibration Mode Bit 6 = Faulted Bit 7 = Ready Bit 8 = Busy Bit
9
=
Not
Configured
Bit 10 = Load Mode Bit
1
1
=
Configured
Without
Job
#.
Bit 12 =
Auto-tune Mode
Bit 13 =
Transparent Mode
Bit 14 =
Analog Hold
Bit 15 = Spare
<07>
Request for Gun Process data: <07> Where: 1) = message length = <00>.
Response: <07> Where: 1) = message length = <14h>. 2) = Latest Error Code 3) = Oldest Error Code
33
