Command T
ype (hex)
Response Or
Action From User Interface
Response Or
Action From Interface Module
<10>
Request to Reset
All Calibration T
otals for a Channel for
a Job: <10><0C> Where: 1) = message length = <02h>. 2) <0C> = Channel #. 3) = Job #
Response: ACK
<1
1>
Request to Copy
All Job Parameters from Gun/Job to a
Range of Gun W/Job X to Gun
Y/Job Z:
<1
1>
Where: 1) = message length = <06h>. 2) <0G> = Source Gun #. 3) = Source Job #. 4) = Starting
Target Gun #.
5) = Starting
Target Job #.
6) = Ending
Target Gun #.
7) = Ending
Target Job #.
See
Types <02> and <09> to see what information is transferred.
Response: ACK Note: W
ait 200 milliseconds before issuing another command
to allow the Interface Module time to complete the transfer
.
<12>
Request to Copy a Single Job Parameter from Gun/Job to a Range of Gun W/Job X to Gun
Y/Job Z:
<12> Where: 1) = message length = <07h>. 2) = Parameter # (see below). 3) = Source Gun #. 4) = Source Job #. 5) = Starting
Target Gun #.
6) = Starting
Target Job #.
7) = Ending
Target Gun #.
8) = Ending
Target Job #.
Response: ACK Note: W
ait 200 milliseconds before issuing another command
to allow the Interface Module time to complete the transfer
.
37
DynaFlow Programer's Manual - Introduction
Ransburg
LN-9406-00.3
