Technical Specifications
A-5
Asanté FriendlyNet cards and Apple computers and printers with
built-in Ethernet do not directly connect to the Ethernet cable;
instead, an external transceiver, like the Asanté FriendlyNet Media
adapter, is used. This approach lets you change network media by
only changing the external adapter instead of the card.
The following table describes the AUI connector pinouts.
GND
Circuit
Signal name
09
TX+
Transmit +
10
TX–
Transmit –
02
RX+
Receive +
03
RX–
Receive –
05
CD+
Collision Detect +
06
CD–
Collision Detect –
07
+5 V
04
GND
Pin
Circuit
Signal name
03
10
11
DO+
DO–
DO S
Data Out + (transmit pair)
Data Out –
Data Out Shield
05
12
04
DI+
DI–
DI S
Data In + (transmit pair)
Data In –
Data In Shield
07
15
08
CO+
CO–
COS
Control Out + (optional)
Control Out –
Control Out Shield
02
09
01
CI+
CI–
CI S
Control In + (optional)
Control In –
Control In shield
06
13
14
VC
VP
VS
Voltage Common (power pair)
Voltage Plus
Voltage Shield
Shell
PG
Protective Ground
