Technical Specifications A-3
MacCon LEDs
The LEDs for the MacCon NuBus, LC, IIsi, and SE cards are described
below.
Ethernet Specifications
The table below lists the Ethernet specifications.
LED State Yellow Green
ON N/A Link Integrity enabled, Twisted pair
cabling used, link detected
Link Integrity disabled, Twisted pair
cabling used
OFF No network
activity Li n k Integrity enabled, Twisted pair
cabling used, no link detected
Link Integrity enabled, thin or thick
cabling used
Blinking Network traffic N/A
Parameter 10Base2 10Base5 10BaseT
Cable Thin Thick UTP
Impedance 50 ohms 50 ohms 100 ohms
Connector on cable BNC DB-15 RJ-45
Data transfer rate 10 Mbps 10 Mbps 10 Mbps
Topology Bus Bus Star
Segment length
(maximum) 185 meters 500 meters 100 meters
Distance between
nodes (minimum) 0.5 meter 1 meter n/a
Nodes per segment
(maximum) 30 500 n/a
