Table 1. The DCS800’s multi-function buttons

Button Label

In Preview Mode

In Playback Mode

In Menu Mode

N/A

In Settings submenu
of Date/Time menu,
highlights field at
left for change

N/A

In Settings submenu
of Date/Time menu,
highlights field at
right for change

Selects next-oldest
video or photo

Selects next-newest
video or photo

Takes a picture (stores

Begins playback of

N/A

.jpg file on SD card)

selected video clip
During playback,
pauses/resumes
playback

Pressed once, starts

N/A

N/A

recording an .avi video
clip on SD card
Pressed again,
stops recording

7

Decreases brightness
of camera lighting
LEDs

Increases brightness
of camera lighting
LEDs

Pressed once, enlarges
target 300% (zooms
3.0X).
Pressed twice, enlarges
target 500% (zooms
5.0X).
Pressed three times,
returns to 1X viewing.

Pressed once, mirrors
video horizontally.
Pressed twice, mirrors
target vertically.
Pressed three times,
mirrors target
horizontally and
vertically.
Pressed four times,
undoes all mirroring.

Moves up one line
within menu or
submenu. In
Settings submenu
of Date/Time menu,
increments value
of highlighted field

Moves down one
line within menu
or submenu.
In Settings submenu
of Date/Time menu,
decrements value
of highlighted field.
