3
PACKAGE CONTENTS:
ቢ 1 Doweling Jig
ባ Brad Point Drill Bits, 1/4", 5/16", 3/8"
ቤ Dowel and Tenon Centers Set from 3/16" ID to 1/2" OD
ብ 3 Drill Stops 1/4", 5/16", 3/8"
ቦ 30 Dowel Pins, 10 Each 1/4", 5/16", 3/8"
ቧ Wood Glue
SAFETY INSTRUCTIONS
1. ALWAYS USE EYE PROTECTION WHEN USING POWER
TOOLS. WEAR SAFETY GOGGLES THAT COMPLY TO
ANSI 287.1.
2. WARNING: ALWAYS UNPLUG DRILL FROM POWER SUPPLY
WHEN CHANGING BITS AND ATTACHING DRILL STOPS.
BEFORE YOU GET STARTED
1. Practice drilling dowel holes and making joints in scrap
pieces of wood to get familiar with the dowel jig.
2. Make all markings on the boards exactly as described in the
instructions to avoid drilling in the wrong locations.
3. Avoid drilling holes too deep.
4. Before gluing dowels, fit the pieces together to make sure
you are satisfied with the line up.
